- 3 x 5.25” tool-less drive bays
- 2 x 2.5” drive bays (dedicated)
- 6 x 3.5” tool-less drive bays
Motherboards: Standard ATX, microATX, Mini-ITX
8 expansion slots
-
Maximum graphics card size: 12.5” (318 mm)
Maximum CPU cooler height: 6.7” (170 mm)
Cooling System:
- 1 x 120 mm rear TwoCool™ fan
- 1 x 140 mm top TwoCool™ fan
- 2 x 120 mm front intake fans (optional)
- 1 x 120 mm side intake fan (optional)
- 1 x 120 mm side exhaust fan behind motherboard (optional)
Perforated front bezel for maximum air intake
Water cooling support: top water cooling grommets
Enlarged CPU cutout
Front I/O ports:
- 2 x USB 3.0 with internal motherboard connector
- Audio In/Out
No power supply included
Unit Dimensions
- 20.2” (H) x 9” (W) x 18.5”
- 513 mm (H) x 229 mm (W) x 471 mm (D)
Package Dimensions:
- 22.2” (H) x 11.4” (W) x 20.6” (D)
- 565 mm (H) x 290 mm (W) x 525 mm (D)
