Infocus *INFIN112

Display Specifications
IN112
Aspect Ratio (Native) 4:3
Aspect Ratio (Supported) 4:3, 5:4, 16:9, 16:10
Resolution (Native) SVGA (800 x 600)
Resolution (Max) WUXGA (1920 x 1200)
Contrast Ratio 4000:1
3D Capable Yes. Supports PC-based 3D content configured at 720p running at 120Hz signal. DLP Link 3D glasses required.
Closed Captioning Yes
Color Wheel 6-segment, 2x speed
Computer Compatibility PC, Mac
Display Technology DLP
DMS No
Interactive No
Number of Colors 1.07 billion
Projection Presets Presentation, Video, Bright, Whiteboard, Blackboard, Beige Wall, User
Projector Placement Front, Ceiling, Rear
Short Throw No
Split Screen No
Video Compatibility SDTV (NTSC, PAL, SECAM, 480i, 576i), ED/HDTV (480p, 576p, 720p, 1080i, 1080p)
Audio
IN112
Speakers 2W (1 x 2W)
Connectivity (Input/Output)
IN112
Connections VGA x 2, S-Video, Composite, Stereo 3.5mm Mini Jack input, RS232C, USB Mini-B (for control & firmware), Stereo 3.5mm Mini Jack output, VGA Monitor Output
Composite (RCA) 1
Monitor Output VGA
RS232 1
S-Video 1
Stereo 3.5mm Mini Jack Input 1
Stereo 3.5mm Mini Jack Output 1
USB Mini-B 1
VGA 2
Environmental
IN112
Audible Noise (Eco, dBA) 28
Audible Noise (High, dBA) 30
Maximum Altitude (feet) 10000
Maximum Altitude (meters) 3048
Operating Temperature (C) 5 - 35°
Operating Temperature (F) 41 - 95°
Lamp Specifications
IN112
Brightness (Eco) 2200 lumens
Brightness (High) 2700 lumens
Dual Lamps No
Lamp Hours (Eco) 6000
Lamp Hours (High) 5000
Lamp Wattage (Eco) 150
Lamp Wattage (High) 180
Lens / Optical Specifications
IN112
Digital Keystone Correction (Vert.) +/- 40%
Focus Type Manual
H-Sync Max (kHz) 100
H-Sync Min (kHz) 31
Image Offset 15%
Lens Shift No
Lens Type Standard
Lens Zoom Type Manual
Lens Zoom Ratio 1.1:1
Optional Lenses No
Maximum Image Size (width, cm) 762
Maximum Image Size (width, inches) 303
Minimum Image Size (width, cm) 101
Minimum Image Size (width, inches) 40
Projection Distance (max, feet) 39
Projection Distance (max, meters) 11.9
Projection Distance (min, feet) 4.9
Projection Distance (min, meters) 1.5
Throw Ratio 1.97-2.17
V-Sync Max (Hz) 120
V-Sync Min (Hz) 50
Other
IN112
Where Available Worldwide
Approvals UL and c-UL (US/Canada), FCC (US/Canada), CE (Europe)
Menu Languages English, French, German, Italian, Korean, Norwegian, Turkish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Dutch, Polish, Danish, Finnish
Physical Attributes
IN112
Product Dimensions (W x D x H) (in.) 11.81 x 9.25 x 2.76
Product Dimensions (W x D x H) (mm) 284 x 235 x 70
Product Weight (kg) 2.17
Product Weight (lbs.) 4.8
Security Kensington Lock, User PIN, Security Bar
Shipping Dimensions (W x D x H) (in.) 12.99 x 12.99 x 5.9
Shipping Dimensions (W x D x H) (mm) 330 x 330 x 150
Shipping Weight (kg) 3.67
Shipping Weight (lbs.) 8
Power / Electrical
IN112
Power Supply 100-240 Volts at 50-60 Hz
Power consumption (High, Watts) 235
Power consumption (Max, Watts) 260
