Standards
IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted-pair copper)
Auto-negotiation of ANSI / IEEE 802.3 NWay
802.3x Flow Control
Protocol
CSMA / CD
Data transfer rate
Ethernet
- 10 Mbit / s (half duplex)
- 20 Mbit / s (full duplex)
Fast Ethernet
- 100 Mb / s (half duplex)
- 200 Mbit / s (full duplex)
Gigabit Ethernet
- 2000 Mbit / s (full duplex)
Topology
Star
Network Cables
10BASE-T:
- UTP Cat. 3, 4, 5/5e (100m max.)
- EIA/TIA-586 100-ohm STP (100 meters max.)
100BASE-TX, 1000BASE-T:
- UTP Cat. 5/5e (100m max.)
- EIA/TIA-568 100-ohm STP (100 meters max.)
Media Interface Exchange
Automatic detection of MDI / MDIX on all ports
Indicators
The port: Link / Activity / Speed
On the device: Power
