MAC Address Table Size
8K
Switch Fabric
32Gbps Forwarding Capacity
Transmission Method
Store-and-Forward
Diagnostic LEDs
Per Unit: Power
Per Port: Activity/Link, Speed
Packet Buffer Memory
On ship: 512KBytes Buffer Memory per Device
Power Consumption
Power On (Stand by): 3.8 Watts
Max: 11.7 Watts
QoS
802.1p (4 Queues)
Acoustics
0 db
MTBF
828,109 Hours
Interface Options
RJ-45
10BASE-T, 100BASE-TX & 1000BASE-T
Network Protocol and Standards
IEEE
802.3 Ethernet, 802.3u Fast Ethernet, 802.3x Flow Control, 802.3ab Gigabit Ethernet, 802.1p Priority Queuing
Electrical & Emissions
Emissions
FCC Class A
CE Class A
ICES-003 Class A
VCCI Class A
C-Tick Class A
Power Supply
100-240VAC, 50/60 Hz Internal Universal Power
Environmental
RoHS Compliant
