Edimax BR-6258NL

Hardware Interface

Management

WAN

•1 x RJ-45 WAN port

•LED Indicators: Power, WPS

•Internal antenna

•WPS/Reset button

•12-language user interface

•System status and security log (web interface)

•Firmware upgradable

•Supports WISP connection mode

•Supports RJ-45 cable/xDSL modems

•WAN protocol: PPPoE, static IP, PPTP, dynamic IP

Security

Output Power & Sensitivity Gain

Installation

•64/128-bit WEP encryption and WPA-PSK, WPA2-PSK security

•802.1x authentication

•Access control

•MAC/IP filter and URL blocking

•SPI anti-DoS firewall

•11n: 14±1.5dBm

•11g: 14±1.5dBm

•11b: 17±1.5dBm

•Multi-language iQ Setup (Web interface)

Humidity & Temperature

Power Adapter

Antenna

•10-90% (Non-condensing)

•0-45oC

•No

•Internal antenna

Dimensions

Weight

 Certifications

•65 (W) x 15.25 (D) x 21.25 (H) mm

•10g

•CE, FCC
