AMD A8-5600K Trinity Quad-Core 3.6GHz (3.9GHz Turbo)
₱4560
General information | |
Type | CPU / Microprocessor |
Market segment | Desktop |
Family | AMD A8-Series |
Model number | A8-5600K |
CPU part numbers |
|
Frequency | 3600 MHz |
Turbo frequency | 3900 MHz |
Package | 904-pin organic lidded micro Pin Grid Array (UOF904) |
Socket | Socket FM2 |
Size | 1.57" x 1.57" / 4cm x 4cm |
Weight | 1.4oz / 39g |
Introduction date | October 2, 2012 |
Price at introduction | $101 |
Architecture / Microarchitecture | |
Microarchitecture | Piledriver |
Platform | Virgo |
Processor core | Trinity |
Core stepping | TN-A1 |
CPUID | 610F01 |
Manufacturing process |
0.032 micron 1303 million transistors |
Die size | 246mm2 |
Data width | 64 bit |
The number of cores | 4 |
The number of threads | 4 |
Floating Point Unit | Integrated (shared between two cores in each module) |
Level 1 cache size |
2 x 64 KB 2-way set associative shared instruction caches 4 x 16 KB 4-way set associative data caches |
Level 2 cache size | 2 x 2 MB 16-way set associative shared exclusive caches |
Level 3 cache size | None |
Cache latency | 3 (L1 cache) |
Multiprocessing | Uniprocessor |
Features |
|
Low power features |
|
Integrated peripherals / components | |
Integrated graphics |
GPU Type: Radeon HD 7560D Shader cores: 256 Base frequency (MHz): 760 |
Memory controller |
The number of controllers: 1 Memory channels: 2 Supported memory: DDR3-1866 Maximum memory bandwidth (GB/s): 29.9 |
Other peripherals |
|
Electrical / Thermal parameters | |
V core | 0.825V - 1.475V |
Maximum operating temperature | 74°C |
Thermal Design Power | 100 Watt |
