AMD FX-8320E Vishera 8-Core 3.2GHz (4.0GHz Turbo)
₱7610
General information | |
Type | CPU / Microprocessor |
Market segment | Desktop |
Family | AMD FX-Series |
Model number | FX-8320E |
CPU part numbers |
|
Frequency | 3200 MHz |
Turbo frequency | 4000 MHz |
Boosted P states [1] |
#1: 4000 MHz, 1.4125V #2: 3500 MHz, 1.225V |
Package |
940-pin organic micro Pin Grid Array (UOC940) Pb-free |
Socket | Socket AM3+ |
Introduction date | September 2, 2014 |
Price at introduction |
$142 (OEM) $146.99 (box) |
Architecture / Microarchitecture | |
Microarchitecture | Piledriver |
Platform | Volan |
Processor core | Vishera |
Core stepping | OR-C0 |
CPUID | 600F20 |
Manufacturing process | 0.032 micron |
Data width | 64 bit |
The number of cores | 8 |
The number of threads | 8 |
Floating Point Unit | Integrated |
Level 1 cache size |
4 x 64 KB 2-way set associative shared instruction caches 8 x 16 KB 4-way set associative data caches |
Level 2 cache size | 4 x 2 MB 16-way set associative shared exclusive caches |
Level 3 cache size | 8 MB 64-way set associative shared cache |
Multiprocessing | Uniprocessor |
Features |
|
Low power features | PowerNow! |
Low power P states [1] |
#1: 2800 MHz, 1.075V #2: 2300 MHz, 1V #3: 1800 MHz, 0.925V #4: 1400 MHz, 0.8375V |
Integrated peripherals / components | |
Integrated graphics | None |
Memory controller |
The number of controllers: 1 Memory channels: 2 Supported memory: DDR3-1866 Maximum memory bandwidth (GB/s): 29.9 |
Other peripherals | HyperTransport technology |
Electrical / Thermal parameters | |
Thermal Design Power | 95 Watt |
