Philips 234E5QHSB

Picture/Display

LCD panel type: AH-IPS LCDBacklight type: W-LED systemPanel Size: 23 inch/58.4 cmEffective viewing area: 509.18 (H) x 286.41 (V)Aspect ratio: 16:9Optimum resolution: 1920 x 1080 @ 60 HzSmartResponse (typical): 5 ms (Grey to Grey)Brightness: 250 cd/m²Contrast ratio (typical): 1000:1SmartContrast: 20,000,000:1Pixel pitch: 0.265 x 0.265 mmViewing angle: 178º (H)/178º (V), @ C/R > 10Picture enhancement: SmartImage LiteDisplay colours: 16.7 MScanning Frequency: 30–83 kHz (H)/56–75 Hz (V)MHL: 1080p@30Hz

sRGB: Yes

Connectivity

Signal Input: HDMI (digital, HDCP), MHL-HDMI (digital, HDCP), VGA (Analogue)Sync Input: Separate Sync, Sync on GreenAudio (In/Out): HDMI audio out

Convenience

User convenience: Power On/Off, Menu, 4:3/Wide, Input, SmartImage liteOSD Languages: Brazil Portuguese, Czech, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Turkish, UkrainianOther convenience: Kensington lock, VESA mount (100 x 100 mm)Plug and Play Compatibility: DDC/CI, Mac OS X, sRGB, Windows 7, Windows 8

Stand

Tilt: -5/20 degree

Power

On mode: 28.4 W (typ.)Standby mode: 0.5 W (typ.)Off mode: 0.3 W (typ.)Power LED indicator: Operation - White, Standby mode - White (flashing)Power supply: External, 100-240 VAC, 50-60 Hz

Dimensions

Product with stand (mm): 532 x 414 x 213 mmProduct without stand (mm): 532 x 325 x 45 mm

Packaging in mm (W x H x D): 577 x 475 x 105 mm

Weight

Product with stand (kg): 3.46 kgProduct without stand (kg): 3.11 kgProduct with packaging (kg): 5.16 kg

Operating conditions

Temperature range (operation): 0°C to 40°C °CTemperature range (storage): -20°C to 60°C °CRelative humidity: 20–80% %Altitude: Operation: +12,000 ft (3658 m), Non-operation: +40,000 ft (12,192 m)MTBF: 30,000 hour(s)

Sustainability

Environmental and energy: EPEAT Silver, RoHS, Lead-free, Mercury FreeRecyclable packaging material: 100 %

Compliance and standards

Regulatory Approvals: BSMI, CE Mark, cETLus, FCC Class B, GOST, SASO, SEMKO, TUV/ISO9241-307, WEEE

Cabinet

Colour: Black Cherry/BlackFinish: Glossy
